Recent RS-509MG Marine VHF Radio with DSC & GPS

Recent RS-509MG
In stock
Product Details
Brand: Recent

Main Functions

25 watts of power

Small size for easy installation

GPS antenna included

DSC distress calls

ICASA approved

Full dot matrix display

Standard NMEA interface

Speaker vibration draining function

IPX7 waterproof rating

Scan: normal scan and priority scan

Dual/tri-watch functions

Weather channel alarm

Simple combination of arrow keys

Programmable soft keys for smooth operation


Frequency: TX: 156.000-162.000MHz, RX: 156.000-163.425MHz

RF power: 25W/1W

Modulation mode: 16K0G3E(FM), 16K0G2B(DSC)

Frequency stability: +-5ppm

Power supply: DC13.8V (+-15%)

Channel spacing: 25kHz

Antenna impedance: 50

Output impedance (audio): 4

Dimensions (WxHxD): 155×68×86mm

Weight: 721g

NMEA Formats (In): RMC, GGA, GNS, GLL, VTG

NMEA Formats (Out): DSC, DSE, RMC, GSA, GSV

Built-in GNSS module, support GPS, GLONAS, SBAS satellite-based augmentation system (WAAS/EGNOS/MSAS/GAGAN)

Standard NMEA interface (RS-422 protocol)

DSC distress calls in 11 categories, all DSC calls in 3 security categories

Dual receiver, independent DSC dedicated receiver

Manually input GPS latitude and longitude and time

DSC call reception and transmission records can be queried

Channel number display digits selectable: 3 digits(01B)/ 4 digits(2001)

Support latest marine channel standards and DSC protocol standards

In the Box

1 x RS-509MG marine VHF transceiver

1 x Hand microphone

1 x Mic hanger

1 x Swivel mounting bracket

1 x PC power cable

1 x GPS antenna

1 x Manual
